CargoMaster CC200
The CC series - Redefined to Maximize Efficiency, Speed & Time
Featuring New State of the Art Technology
- ComfortStep Feature and the Multi-Levelled Battery display set
new standards concerning handling and safety of Sensitive Goods.
Comfort Landing at Every Step, Seamless Curved-like body structure, Reinforced Adjustable Handles to master any situation for a widened range of goods
> Comfort Step function convinces by quietly and softly touching down on the
step making it an indispensable aid for the transportation of even highly
sensitive loads.
> Integrated Battery Display keeps user Informed at all times on the actual
battery charge left and offers indication when required to be recharged.
> Safety Compliant, Uniquely Designed, AAT BRAKING SYSTEM
Which stops automatically at the edge of a step, the CC series becomes your
new reliable partner for any type of transportation problem.
Featuring New State of the Art Technology
- ComfortStep Feature and the Multi-Levelled Battery display set
new standards concerning handling and safety of Sensitive Goods.
Comfort Landing at Every Step, Seamless Curved-like body structure, Reinforced Adjustable Handles to master any situation for a widened range of goods
> Comfort Step function convinces by quietly and softly touching down on the
step making it an indispensable aid for the transportation of even highly
sensitive loads.
> Integrated Battery Display keeps user Informed at all times on the actual
battery charge left and offers indication when required to be recharged.
> Safety Compliant, Uniquely Designed, AAT BRAKING SYSTEM
Which stops automatically at the edge of a step, the CC series becomes your
new reliable partner for any type of transportation problem.
Book A Free Demo
CC200 is powered stair climber that can carry up to 200kg as the Comfort Step and a multi-leveled battery display in order to provide handling and ease of use.
CLICK HERE TO SEE VIDEO
See the CargoMaster in action.
Videos describing the climbing process and how to use the CargoMaster.
Videos describing the climbing process and how to use the CargoMaster.
Comfort Step
- Soft Touching Down
- Low-Vibration Climbing
- Comfortable Climbing
- With Integrated battery Display
- Also Suitable for High Quality Loads
- Can be Turned On at All Times
CargoMaster CC200 Technical Data
| Model | CC200 |
| Measurement | Height : 1065-1490mm Width : 466mm Depth with toe-plate hinged/folded down = 290 / 530 mm |
| Weight | Climbing unit = 25.8 kg Battery pack = 4.1 kg Total weight = 29.9 kg |
| Lifting capacity | 200 kg |
| Climbing speed | 6 - 19 steps / minute, continually adjustable |
| Range with one charge of the batteries | Approx. 18 - 31 levels (equates 225 - 450 steps) |
| Maximum height of step | 210 / 225mm (extended) |
| Necessary step width (straight stairs) | Width : CargoMaster + Load + 100 mm |
| Min. platform size (U-shaped stairs) | Depends on the attendant’s height |
| Batteries | 2 x 12 V / 5 Ah (sealed lead acid) |
| Direct current motor | 24V/275V |
| Sound pressure level | < 70db |
| Storing/operating temperature, device | 0° C bis +60° C / -30° C bis +50° C |
| Storing/operating temperature, batteries | 0° C bis +60° C / -30° C bis +50° C |
| Vibrations | The weighted RMS value of acceleration the upper body is exposed to lies typically below 2.5 m/s² |
| Sticker serial number | On the left side of the housing |
| IP-Protection class | IPX4 protection class: Protection against splash water from all sides |
Download Brochure CargoMaster CC200
Loading ...
Front Plate
Made of safety plexiglass to protect the goods from sliding through or from scratching.
Back Wall
Made of aluminum with a felt cover to protect the goods from sliding through and from scratching.
Transportation Wheel
Loads can be pushed on level ground with very little physical effort. Thus, very quickly you can switch from stair climbing to wheeling goods on level ground. Also, higher goods can be transported through doors that way.
Support for white goods
Lock of The Toe Plate
Support for round containers
With a diameter of approximately 150 - 800 mm to protect round goods. Easy assembly by popping it on.
Auxiliary stairs made of steel (Able to support loads of 350-500kg)
Boot extends between 480mm – 900mm in height.
