MAX 2

The Max 2 is powered by a strong electric motor, where energy is provided by the rechargeable batteries. It is adaptable to almost all types of wheelchairs, where the steering to the drive is not as otherwise common -- via joysticks or a central steering column but in a classic way via two operating grips.

Send Enquiry

Book A Free Demo

Loading ...

Book A Free Demo

The Versatile Electric Drive

The Max 2 is powered by a strong electric motor, where energy is provided by the rechargeable batteries. It is adaptable to almost all types of wheelchairs, where the steering to the drive is not as otherwise common - via joysticks or a central steering column but in a classic way via two operating grips.

The transmission of power is controlled by two drive shafts catching the steering of the powered wheels'.

Advantages that convince

Lightweight electric drive for own operation
Intuitive direct steering with powerful motor speeds up to 5.5 km/h
Can be used as pushing and braking aid as well to ease pushing the wheelchair uphill or difficult terrains
Simple add-on Plug & Play adaptability
Adaptable to almost all commercially types of wheelchairs
Easy storage, lightweight, compact & manoeuvrable

CLICK HERE TO SEE STAIRCLIMBER WHEELCHAIRS IN ACTION

See the Max 2 in action.
Videos describing the climbing process and how to use the Max 2.

MAX 2 Technical Data

Technology	MAX 2
Total weight approved ⁽¹⁾	200 kg (Person, Rollstuhl, max 2)
Max. weight of the person	-
Possible wheel sizes	24"
Speed forward I backward	adjustable 5,5 km/h 13 km/h
Range with one charge of the batteries ⁽²⁾	up to 18 km
Braking-/climbing capacity ⁽³⁾	up to 20%
Batterie technology	lead acid
Batteries	2 x 12 V / 16 Ah
Direct current motor	24 V / 150 W
Weight, powered wheels	-
Weight, drive unit	8,7 kg (incl. handles)
Weight, batteries	10,2 kg
Weight, control unit	-
Weight, steering	6,5 kg
Weight, bag for battery pack	0,2 kg
Weight, interface	-
Total weight	26,1 kg
