The Max 2 is powered by a strong electric motor, where energy is provided by the rechargeable batteries. It is adaptable to almost all types of wheelchairs, where the steering to the drive is not as otherwise common -- via joysticks or a central steering column but in a classic way via two operating grips.
Loading ...
Book A Free Demo
Loading ...
Close
Share:

The Versatile Electric Drive

The Max 2 is powered by a strong electric motor, where energy is provided by the rechargeable batteries. It is adaptable to almost all types of wheelchairs, where the steering to the drive is not as otherwise common - via joysticks or a central steering column but in a classic way via two operating grips.

The transmission of power is controlled by two drive shafts catching the steering of the powered wheels'.

Advantages that convince

  • Lightweight electric drive for own operation
  • Intuitive direct steering with powerful motor speeds up to 5.5 km/h
  • Can be used as pushing and braking aid as well to ease pushing the wheelchair uphill or difficult terrains
  • Simple add-on Plug & Play adaptability
  • Adaptable to almost all commercially types of wheelchairs
  • Easy storage, lightweight, compact & manoeuvrable
MAX 2 IN ACTION
See the Max 2 in action.
Videos describing the climbing process and how to use the Max 2.
LET'S ROCK! >
MAX 2 Technical Data
Technology MAX 2
Total weight approved (1) 200 kg (Person, Rollstuhl, max 2)
Max. weight of the person -
Possible wheel sizes 24"
Speed forward I backward adjustable 5,5 km/h 13 km/h
Range with one charge of the batteries (2) up to 18 km
Braking-/climbing capacity (3) up to 20%
Batterie technology lead acid
Batteries 2 x 12 V / 16 Ah
Direct current motor 24 V / 150 W
Weight, powered wheels

-
Weight, drive unit 8,7 kg (incl. handles)
Weight, batteries 10,2 kg
Weight, control unit -
Weight, steering 6,5 kg
Weight, bag for battery pack 0,2 kg
Weight, interface -
Total weight 26,1 kg



Download Brochure MAX 2
